Products Description
Product Highlights
Ultra-Precision Double-Side Polishing：
Achieves flatness error ≤0.002mm, ideal for parts requiring ultra-high flatness and parallelism.
Independent Motor Control：
Upper/lower plates and internal gears adjustable individually for speed and direction to meet different processing requirements.
Flexible Workpiece Handling：
Outer gear ring with automatic and jog lift functions enables easy workpiece loading/unloading and planetary wheel height adjustment.
Advanced Dressing System：
Servo-driven dressing arm rotates forward/backward with controllable speed; can dress upper and lower plates simultaneously, achieving flatness ≤0.005mm.
Smart & Reliable Operation：
Frequency-controlled motors with soft start/stop and shock-free forward/reverse rotation; touch-screen digital interface for intuitive and visual parameter control.
| ZY60S 单面研磨抛光机主要参数 | |||
Grinding Plate Size (mm) | Φ640*284 | Grinding Plate / Internal Gear Speed （r.p.m） | 0~50 |
Number of Fixtures | 5 | Minimum Workpiece Thickness (mm) | 0.3 |
Maximum Workpiece Diameter （mm） | Ф150 | WorkingAir Pressure （Mpa） | 0.4~0.5 |
Machine Weight | 3400KG | PowerSupply Voltage | Three-phase Five-wire 380V |
Overall Dimensions （W*D*H）mm | 1900*1700*2300 | Total Power | 13KW |
